Synchronous Motor 18.5KW 22KW 3 Phase Frequency Inverter Wide Applications
Place of Origin China
Brand Name VEIKONG
Certification CE
Model Number VFD530
Minimum Order Quantity 1
Price Negotiable
Packaging Details Carton and Wooden Box
Delivery Time 3 days, depend on the order quantity
Payment Terms Western Union, T/T, L/C, D/A, D/P, PayPal
Supply Ability 15000pcs per Month
Product Details
Product Name 18.5KW 22KW 3 Phase Output Frequency Inverter Current 37A And 45A
Weight 10kg Size 370*210*205mm
Frequency 50HZ/60HZ Control Mode VF, SVC, VC, Torque Control, Tension Control
High Light

22KW 3 Phase Frequency Inverter

,

18.5KW 3 Phase Frequency Inverter

Product Description

18.5KW 22KW 3 Phase Output Frequency Inverter For Synchronous Motor



Product Feature



High performance general purpose ac drive, VFD530 Effortless process automation for a broad range of applications



VEIKONG VFD530 general purpose AC drives simplify your processes and motor control with effortless process automation.



The VFD530 is a good choice for a wide range of applications, making it easy to comprehensively manage your plant.



The VFD530 is part of VEIKONG ’s all-compatible drives portfolio, sharing the same architecture and user interfaces for easy usability.



The VFD530 is plug-in ready to control your compressors, conveyors, mixers, pumps, centrifuges, fans and many other variable and constant torque applications in different industries.



Synchronous Motor 18.5KW 22KW 3 Phase Frequency Inverter Wide Applications



Model Range



Model

Power capacity

(KVA)

Input current

(A)

Output current(A)

Adaptable Motor

(KW)

SIZE

Brake Unit

Heavy load

Light load

Three phase: 380-480V,50/60Hz

VFD530-R75GT4B

1.5

3.4

2.5

4.2

0.75

SIZE A

Internal

VFD530-1R5GT4B

3

5

4.2

5.6

1.5

VFD530-2R2GT4B

4

5.8

5.6

9.4

2.2

VFD530-4R0G/5R5PT4B

5.9

10.5

9.4

13.0

3.7

VFD530-5R5G/7R5PT4B

8.9

14.6

13.0

17.0

5.5

SIZE B

VFD530-7R5G/011PT4B

11

20.5

17.0

23.0

7.5

VFD530-011G/015PT4B

17

26.0

25.0

31.0

11

SIZE C

Internal

VFD530-015G/018PT4B

21

35.0

32.0

37.0

15

VFD530-018G/022PT4B

24

38.5

37.0

45.0

18.5

SIZE D

VFD530-022G/030PT4B

30

46.5

45.0

57.0

22

VFD530-030G/037PT4

40

62.0

60.0

75.0

30

SIZE E

option

VFD530-037G/045PT4

50

76.0

75.0

87.0

37

VFD530-045G/055PT4

60

92.0

90.0

110.0

45

SIZE F

VFD530-055G/075PT4

75

113.0

110.0

135.0

55

VFD530-075G/090PT4

104

157.0

152.0

165.0

75

SIZE G

VFD530-090G/110PT4

112

170.0

176.0

210.0

90

External

VFD530-110G/132PT4

145

220.0

210.0

253.0

110

SIZE H

VFD530-132G/160PT4

170

258.0

253.0

304.0

132

SIZE I

VFD530-160G/185PT4

210

320.0

304.0

360.0

160

VFD530-185G/200PT4

245

372.0

360.0

380.0

185

SIZE J

VFD530-200G/220PT4

250

380.0

380.0

426.0

200

VFD530-220G/250PT4

280

425.0

426.0

465.0

220

SIZE K

VFD530-250G/280PT4

315

479.0

465.0

520.0

250

VFD530-280G/315PT4

350

532.0

520.0

585.0

280

SIZE L

VFD530-315G/355PT4

385

585.0

585.0

650.0

315

VFD530-355G/400PT4

420

638.0

650.0

725.0

355

SIZE M

VFD530-400G/450PT4

470

714.0

725.0

820.0

400

VFD530-450G/500PT4

530

800.0

820.0

/

450

SIZE N

VFD530-500G/560PT4

580

880.0

900.0

/

500

VFD530-560G/630PT4

630

950.0

980.0

/

560

SIZE O

VFD530-630GT4

710

1080

1120.

/

630

SIZE O

VFD530-710GT4

790

1200

1260

/

710

SIZE O

Single phase :220V ,50/60HZ

VFD530-R40GS2

1.3

6.0

3.2

5.6

0.4

SIZE A

Inbuilt

VFD530-R75GS2

2.4

11.0

5.6

8.0

0.75

SIZE A

VFD530-1R5GS2

3.5

15.0

8.0

10.6

1.5

SIZE A

VFD530-2R2GS2

5.5

25.0

10.6

14.0

2.2

SIZE A

VFD530-4R0GS2

7.7

35.0

17.0

23.0

4.0

SIZE B

VFD530-5R5GS2

8.9

53.0

25.0

31.0

5.5

SIZE C

VFD530-7R5GS2

11

67.0

32.0

37.0

7.5

SIZE C



Product Application



Synchronous Motor 18.5KW 22KW 3 Phase Frequency Inverter Wide Applications



Synchronous Motor 18.5KW 22KW 3 Phase Frequency Inverter Wide Applications



FAQ



1. What's the shipping method?



We support ship by express, by air and by sea. And we will recommend the most suitable shipping way to you according to your order list.



2. How are your products packaged?



0.75kw-37kw use carton, 45kw and above use wooden box.



3. Do you accept OEM order?



Yes we accept OEM order with your authorization.
